MX524 5-Channel Analog Mixer

$369.99

We Like Deals!


The ART MX524 Five Channel Four Zone Mic/Line Mixer is a versatile rack mount mixer that combines Five independent input channels and routes them to four zone outputs. Channels one thru four accept a balanced Line or Mic signal thru the Combo jack connector. CH5 accepts a line level signal through RCA jacks. The unit has an independent selectable +48 Volt phantom power function for channels one thru four. Channels one thru four can also accept unbalanced line-level signals. Each channel has a level control and can be routed to any zone output. Separate level, bass and treble controls adjust the sound of each input channel. The ART MX524 may be used on stage, in the studio, or for permanent install applications including conference rooms, corporate boardrooms, churches, restaurants, small clubs, health clubs and more. A built-in power supply and triple high 19-inch rack mount format allows for easy installation and reliable long-term operation.

Features

  • Five Input Channels with Individual Level Controls Using XLR/Phono Jacks
  • Balanced Mic/Line XLR Inputs for Channels One Through Four
  • Front Panel 1/8-Inch Stereo (TRS) Mini-Phone Plug for Headphone Monitoring
  • Telephone Paging Function
  • Rear Mount RCA Line Inputs for Additional Audio Inputs
  • Rugged 3U Rack-Mount Steel Chassis with Built-In Power Supply

Specifications

# of Channels
5
# of Mic Inputs
4
Dimensions
5" H x 19" W x 7.5" D
EQ
3-Band EQ
Features
Rackmountable
Inputs
4 x XLR / 1/4 Combo Jacks, 1 x RCA
MPN
MX524
Outputs
4 x Euroblock, Screw terminals
Power Source
48V Phantom Power
Processing Type
Analog
UPC
0000840402048640
