WH10V3 Wah Effects Pedal
$159.99
We Like Deals!
WH10 series has remained a highly popular wah pedal through the years due to its many unique features. The guitar/bass range switch enables switching between two preset frequency ranges best suited for each instrument. This is also the first wah pedal to utilize a multiple feedback opamp circuit, creating a much different tonal quality versus more common inductor based wahs. There is also a volume boost for additional flexibility. The WH10V3 features selectable true or buffered bypass, and circuitry is housed in a highly-durable, die-cast Aluminum alloy body with a distinctive black finish.
Features
- Controls: Depth
- Switches: Effect ON/OFF, Frequency range(Guitar/Bass), Buffered/True Bypass
- I/O's: Input, Output Input is on the right side. Output is on the left side.
- Size: 100(W) x 202(D) x 84(H)(mm)
- Weight: 815g
- Required Current: 12mA@9V
- Power supply: One 9 volt battery or External DC 9 volt AC adapter
Specifications
Batteries
1 x 9V
Dimensions
3.3" H x 3.93" W x 7.95" D
Effects
Wah
Features
Battery-Powered
Inputs
1 x 1/4"
MPN
WH10V3
Outputs
1 x 1/4"
Power Source
9V DC power supply (sold separately)
Power Usage
12mA
Processing Type
Analog
UPC
0004549763213754
Weight
1.8 lbs
